What Are the Structural Types of LED Digital Tubes?
* Answer
LED digital tubes, also known as seven-segment LED displays, are electronic display devices used to show numbers and limited characters.
Their structures are defined by electrical connection method, physical packaging, and display configuration, each affecting driving方式、应用场景和系统设计。
Below are the main structural types of LED digital tubes.
1. Common-Cathode Structure
Structure Description
- All LED cathodes are connected together internally
- Individual segments are controlled by applying a HIGH levelto the anodes
Electrical Characteristics
- Requires the driver to source current
- Common in TTL/CMOS logic-driven designs
Typical Applications
- Microcontroller-based systems
- Educational and industrial display modules
2. Common-Anode Structure
Structure Description
- All LED anodes are internally connected
- Segments light up when a LOW levelis applied to the cathodes
Electrical Characteristics
- Requires the driver to sink current
- Widely used with transistor arrays and driver ICs
Typical Applications
- High-current display driving
- Systems using ICs like ULN2803or LED driver chips
3. Single-Digit vs. Multi-Digit Structures
Single-Digit LED Digital Tubes
- Contain one complete seven-segment display
- Simple wiring and control
Multi-Digit LED Digital Tubes
- Combine multiple digits in one package
- Often use multiplexed scanningto reduce pin count
Common formats include:
- 2-digit
- 4-digit
- 6-digit displays
4. Integrated Decimal Point (DP) Structure
Most LED digital tubes include a decimal point LED, which:
- Is electrically independent
- Requires separate control
- Expands numeric display capability
This is especially important for measurements such as voltage, current, or frequency.
5. Package and Assembly Structures
Through-Hole (DIP) Packages
- Traditional pin-through-hole design
- Strong mechanical stability
Surface-Mount (SMD) Packages
- Compact size
- Suitable for automated assembly
Light-Emitting Orientation
- Front-emitting (standard)
- Side-emitting (used in slim enclosures)
Engineering Insight
Selecting the correct LED digital tube structure directly impacts:
- Driver circuit complexity
- Power consumption
- MCU I/O resource usage
- Brightness uniformity
For example, common-anode displays are often preferred in high-current, multi-digit scanning applications, while common-cathode displays simplify logic-level interfacing.
Conclusion
LED digital tubes can be structurally classified by:
- Electrical connection type: common-cathode and common-anode
- Display configuration: single-digit and multi-digit
- Functional integration: with or without decimal point
- Physical packaging: DIP or SMD
Understanding these structures helps engineers select suitable display modules and design reliable driver circuits for embedded and industrial applications.
