    What is a multi-rack link aggregation or a cross-stack Ethernet channel?

    * Answer

    A multi-rack link aggregation or cross-stack Ethernet channel refers to a network design technique that enables logical bundling of Ethernet links across multiple physical switches—typically in different racks or chassis—into a single logical channel. This approach enhances resiliency, load balancing, and redundancy in high-availability data center and enterprise network architectures.

    1. Concept Overview

    ➤ Multi-Rack Link Aggregation:

    This involves creating a Link Aggregation Group (LAG)—also called an EtherChannel—that spans multiple top-of-rack (ToR) switches. The aggregated link appears as a single interface to the connected device (like a server or another switch), even though it physically terminates on separate switches.

    ➤ Cross-Stack EtherChannel:

    This is a similar concept, where switches in a stacked configuration (or virtual chassis) jointly participate in a single EtherChannel. It’s often vendor-specific:

    Cisco: Called Multi-Chassis EtherChannel (MEC) or StackWise EtherChannel

    Arista: Uses MLAG (Multi-Chassis Link Aggregation)

    Juniper: Uses Virtual Chassis and LAGs

    Dell/Force10: Uses VLT (Virtual Link Trunking)

    2. Key Characteristics

    Feature

    Description

    Resiliency

    If one switch or link fails, traffic continues through the other links/switches.

    Load Balancing

    Traffic is distributed across all member links based on hashing algorithms.

    Single Logical Interface

    To the connected server/switch, the group of physical links appears as one.

    Requires Vendor Support

    Not all switches support cross-stack LAG; it depends on firmware, models, and vendor features.

    3. Use Case Example

    Imagine a high-performance server with two NICs:

    NIC 1 connects to Switch A (Rack 1)

    NIC 2 connects to Switch B (Rack 2)

    Using cross-stack link aggregation:

    The server configures a bonded interface (LACP or static) across NIC 1 and NIC 2

    Switch A and B are configured for MLAG or equivalent, and coordinate state and forwarding

    Result: Higher throughput + failover protection + seamless connectivity

    4. Standards & Protocols

    IEEE 802.3ad / IEEE 802.1AX: Standard for LACP (Link Aggregation Control Protocol)

    Proprietary Enhancements:

    Cisco vPC (Virtual Port Channel)

    Arista MLAG

    Juniper MC-LAG

    HPE IRF (Intelligent Resilient Fabric)

    5. Benefits

    High availability across physical infrastructure

    No spanning-tree blocking (since links are active-active)

    Seamless integration with NIC bonding on servers

    Horizontal scalability in spine-leaf and ToR networks

    Summary

    A multi-rack link aggregation or cross-stack EtherChannel provides a way to combine multiple Ethernet links across different switches into a single logical interface, delivering high availability and balanced throughput. It is essential in modern redundant network topologies, especially in data center, cloud, and enterprise networks.
